BETTY Dataset: A Multi-modal Dataset for Full-Stack Autonomy


1Robotics Institute, Carnegie Mellon University
2University of Modena and Reggio Emilio
3University of Pittsburgh
4University of Waterloo

Abstract

We present the BETTY dataset, a large-scale, multi-modal dataset collected on several autonomous racing vehicles, targeting supervised and self-supervised state estimation, dynamics modeling, motion forecasting, perception, and more. Existing large-scale datasets, especially autonomous vehicle datasets, focus primarily on supervised perception, planning, and motion forecasting tasks. Our work enables multi-modal, data-driven methods by including all sensor inputs and the outputs from the software stack, along with semantic metadata and ground truth information. The dataset encompasses 4 years of data, currently comprising over 13 hours and 32 TB, collected on autonomous racing vehicle platforms. This data spans 6 diverse racing environments, including high-speed oval courses, for single and multi-agent algorithm evaluation in feature-sparse scenarios, as well as high-speed road courses with high longitudinal and lateral accelerations and tight, GPS- denied environments. It captures highly dynamic states, such as 63 m/s crashes, loss of tire traction, and operation at the limit of stability. By offering a large breadth of cross-modal and dynamic data, the BETTY dataset enables the training and testing of full autonomy stack pipelines, pushing the performance of all algorithms to the limits.

⚠️ Disclaimer

As post-processing continues, we currently are providing a small subset of the data with all but the Goodwood track. This includes 6 runs, encompassing high- & low-speed and single- & multi-agent scenarios, as well as those with loss of traction. Please see our preliminary easy-access visualizations of perception and dynamics data below.

Visualizations

Visualize our data! Select one of the tracks to view camera, LiDAR, and timeseries data from this track.

Las Vegas Motor Speedway

Las Vegas

Lucas Oil

Indianapolis

Texas

Monza

Goodwood

See complete visualizations in Foxglove

Note: Foxglove account required. Visualization is currently very slow.

BibTeX


      Coming soon
